Panasonic DP-2330

256
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
LDPHK4 Photo Sensor DC Drive Voltage
LDPS Photo Sensor DC Drive Voltage
LDRSEN Photo Sensor DC Drive Voltage
LDTF Photo Sensor DC Drive Voltage
LDUPL Photo Sensor DC Drive Voltage
LDUPL2 Photo Sensor DC Drive Voltage
LDUPL3 Photo Sensor DC Drive Voltage
LDUPL4 Photo Sensor DC Drive Voltage
LDWTD Photo Sensor DC Drive Voltage
LEDA Select Sensor Signal
LEDC Select Sensor Signal
LEDX Select Sensor Signal
LEDY Select Sensor Signal
LEDZ Select Sensor Signal
LPOW1 Low Power Control 1
LPOW2 Low Power Control 2
MCLK+ Master Clock +
MCLK- Master Clock -
MGND Ground
N.C. Not Used
n2WAYKEP1 Paper Stopper Solenoid Signal
n2WAYKEP2 Paper Stopper Solenoid Signal
n2WAYSEN Inner Upper Tray Paper Exit Signal
nA3SEN Sheet Bypass Paper Size Detection Signal
nAA3S Original Width Detection Signal
nAADL1 Original Length Detection Signal
nAADL2 Original Length Detection Signal
nAAPNT Original Detection Signal
nAB1SN Read Point Detection Signal
nAB2SN Duplex Eject Detection Signal
nAB4S Original Width Detection Signal
nACLOCKAD1 ADF Motor Control Clock Signal
nADF3 3rd Paper Tray Feed Roller Drive Signal
nADF4 4th Paper Tray Feed Roller Drive Signal
nAEJC Original Eject Detection Signal
nAKEEP1 Reversing 1 Guide Solenoid Control Signal
nAKEEP2 Reversing 1 Guide Solenoid Control Signal
nAOAC ADF Cover Open Detection Signal
nAPACHG Duplex 2 Guide Solenoid Control Signal
nAPICR Release Lever Plate Solenoid Control Signal
nAREV ADF Exit Cover Open Detection Signal
nASTAMP Stamp Control Signal
nASTROAD1 ADF Motor Control Strobe Signal
nATT Attention Signal
nB4SEN Sheet Bypass Paper Detection Signal
nCASET Paper Tray Detection Signal (1st Feeder)
nCCLH1 Feed 2 Roller Clutch Control Signal
Signal Name Function
