nCCLH2 ADF Roller Clutch Control Signal
nCCLH3 Inverting Roller Clutch Control Signal
nCLPIN AFE Sample Hold Clamp Signal
nCOUNT Counter Drive Signal
nCST2 2nd Paper Tray Detection Signal
nCST3 3rd Paper Tray Detection Signal
nCST4 4th Paper Tray Detection Signal
nCSTOP 2nd Paper Feed Module Detection Signal
nCSTOP4 4th Paper Feed Module Detection Signal
nCTON Ring Detection Signal
nDADFON ADF Option Detection Signal
nDOOR Paper Transport Unit Open Detection Signal
nDUACK Duplex Print Acknowledge Signal
nDUPSEN1 Duplex Sensor 1 Signal
nDUPSEN2 Duplex Unit Paper Detection Signal
nDUPSEN3 Duplex Unit Paper Detection Signal
nDUPSEN4 Duplex Unit Paper Detection Signal
nDUREQ Duplex Print Request
nESEN Inner Exit Tray Paper Detection Signal
nEXDF1 Paper Transport Unit Paper Detection Signal
nEXDF2 Paper Transport Unit Paper Detection Signal
nEXDF3 Paper Transport Unit Paper Detection Signal
nEXDF4 Paper Transport Unit Paper Detection Signal
nFDPCHK2 2nd Paper Tray Paper Registration Detection Signal
nFDPCHK3 3rd Paper Tray Paper Registration Detection Signal
nFDPCHK4 4th Paper Tray Paper Registration Detection Signal
nFNRDT Fan Ready Signal
nFNRDTB Scanner Fan Ready Signal
nFNRDTL LSU Fan Ready Signal
nFNRDTP LVPS Fan Ready Signal
nGARST CCD PCB Reset Signal
nHDF Multi Feeder Feed Roller Drive Signal
nHKOF External Phone Off-Hook Detection Signal
nHTJAM Fuser Unit Jam Sensor Signal
nIMMP0a Motor Drive Signal
nIMMP0b Motor Drive Signal
nJAMDOR2 2nd Paper Tray Jam Access Cover Open Detection Signal
nJAMDOR3 3rd Paper Tray Jam Access Cover Open Detection Signal
nJAMDOR4 4th Paper Tray Jam Access Cover Open Detection Signal
nKCNT Key Counter Option
nKEEP1 Paper Stopper Solenoid Signal
nKEEP2 Paper Stopper Solenoid Signal
nLIFT1 1st Paper Tray Lift Motor Signal
nLIFTM2 2nd Paper Tray Lift Motor Drive Signal
nLIFTM3 3rd Paper Tray Lift Motor Drive Signal
nLIFTM4 4th Paper Tray Lift Motor Drive Signal
nLPOW1 Not Used
