Panasonic DP-2330

258
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
nLPOW2 Not Used
nMFPCK Sheet Bypass Paper Detection Signal
nMFRCHK Sheet Bypass Pressure Plate Detection Signal
nMFSEN4 Sheet Bypass Paper Length Detection Signal
nMMCK Main Motor Clock
nMMON Main Motor Rotation Control Signal
nMMP0a Motor Drive Signal
nMMP0b Motor Drive Signal
nMMRDY Main Motor Ready Signal
nMRCLH3 3rd Paper Tray Intermediate Roller Clutch Drive Signal
nMRCLH4 4th Paper Tray Intermediate Roller Clutch Drive Signal
nOE Output Enable (Image Data)
nOP2WAY 2Way Unit Detection Signal
nOP3ENB Option Feed FIFO Enable
nOP3FCK Option Feed FIFO Clock
nOP3FDIN Option Feed FIFO Input
nOP3FLD Option Feed FIFO Load
nOP3FLT Option Feed FIFO Latch
nOP3FOT Option Feed FIFO Otput
nOP3RST Option Feed FIFO Reset
nOPDUP Duplex Unit Detection Signal
nOPTRP Transport Unit Installed Detection Signal
nORI Home Position Detection Signal
nPACK Printer ACK Signal
nPCHK1 1st Paper Tray Paper Detection Signal
nPCHK2 2nd Paper Tray Paper Detection Signal
nPCHK3 3rd Paper Tray Paper Detection Signal
nPCHK4 4th Paper Tray Paper Detection Signal
nPMON Polygon Motor Rotation Signal
nPMRDY Polygon Motor Ready Signal
nPNLRST Panel Reset Signal
nRRCLH Registration Roller Drive Signal
nPRDY Printer Ready Signal
nPRGDWN F-ROM Rewrite
nRSEN Registration Sensor Signal
nPVSYNC Print Registration
nS/H Sample Hold Signal
nSACK Scan ACK Signal
nSEN1 AFE Serial Data Output Enable Signal
nSENTIM Scanner LSYNC Signal
nSREQ Scanner Request Signal
nSSR1 Heater Control Signal
nSSR2 Heater Control Signal
nSSR3 Not Used
nSYNC Horizontal Synchronous Signal
nTNSCLH Toner Clutch Control
nTRPJAM Transport Unit Open Detection Signal
Signal Name Function
