nTRPSEN1 Transport Unit Sensor Signal
nTRPSEN2 Transport Unit Sensor Signal
nTRPSEN3 Transport Unit Sensor Signal
nTRPSEN4 Transport Unit Sensor Signal
nVRDY VSYNC Reset Signal
nVREQ Print ACK Request Signal
nWAKE FAX Wake Up Signal
OPCCNT OPC Drum Clutch Control Signal
OUTA Motor Control Signal
OUTB Motor Control Signal
P/S Motor Start/Stop
pADF2 2nd Paper Tray Feed Roller Drive Signal
pBLKCLP AFE Black Level Clamp Switch Signal
pCMLD Line Switching Relay Drive Signal
PFCLCNT Paper Feed Clutch Drive Signal
pFLON Inverter Ground
pLIFT2 2nd Paper Tray Lift Motor Signal
pLIFT4 4th Paper Tray Lift Motor Signal
PMCK Polygon Motor Clock
pMMP0a Motor Drive Signal
pMMP0b Motor Drive Signal
pMRCLH2 2nd Paper Tray Intermediate Roller Clutch Drive Signal
PNLDO1 Panel F-ROM Rewrite Serial Data
PNLSCK1 PNL1 Serial Clock
POWCNTV Laser Power Control Signal
pPRXD Reception Data Signal
pPTXD Transmission Data Signal
pSPCRST SPC Reset Signal
pSPKOT Line Dial Tone Signal
pTRPKEP1 Transport Unit Solenoid Signal
pTRPKEP2 Transport Unit Solenoid Signal
pTRPMDA Transport Unit Motor Signal
pTRPMDB Transport Unit Motor Signal
pTRPMNA Transport Unit Motor Signal
pTRPMNB Transport Unit Motor Signal
pUPLIMIT1 1st Paper Tray Paper Level Signal
pUPLIMIT2 2nd Paper Tray Paper Level Signal
pUPLIMIT3 3rd Paper Tray Paper Level Signal
pUPLIMIT4 4th Paper Tray Paper Level Signal
pVREF1 Transport Unit Motor Current Setup Signal
pVREF2 Transport Unit Motor Current Setup Signal
pZCIN Heater Control Signal
RETRACE Laser Control
SCLK+ AFE Serial Data Clock +
SCLK- AFE Serial Data Clock -
SDI AFE Serial Data Signal
SLPKY Sleep Key
Signal Name Function
