Panasonic DP-2330

260
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
SPCRXD SPC Reception Data Signal
SPCTXD SPC Transmission Data Signal
SPOW Scanner 24V Control Signal
STRVP Control Signal
TDREF Toner Density Reference Sensor
TDSN Toner Density Sensor Signal
TED Toner Detect Sensor Signal
TEMPSN Temp Humidity Sensor Signal
TFSN Toner Waste Sensor Signal
TG TG Signal for Product Line
THERMA1 Fuser Thermistor A1
THERMA2 Fuser Thermistor A2
THERMB1 Fuser Thermistor B1
THERMB2 Fuser Thermistor B2
TR0 Transfer Control Transfer Output
TR1 Transfer Control Cleaning Output
TxCLKOUT+ Image Data Transmission Clock +
TxCLKOUT- Image Data Transmission Clock -
TxOUT0+ Image Data Out 0 +
TxOUT0- Image Data Out 0 -
TxOUT1+ Image Data Out 1 +
TxOUT1- Image Data Out 1 -
VCDS Density Sensor ON
VCNT Inverter Control Signal
VINA Sensor Input Signal
VINX Sensor Input Signal
VOUTA Sensor Control Signal
VOUTB Sensor Control Signal
VOUTX Sensor Control Signal
VTED Toner Detect Sensor ON
WEBSOL Web Solenoid Control Signal
WTBSN Toner Waste Container Detection Sensor Signal
X1 Touch Panel Matrix Signal
X2 Touch Panel Matrix Signal
Y1 Touch Panel Matrix Signal
Y2 Touch Panel Matrix Signal
Signal Name Function
