Panasonic DP-2330

194
DP-2330/3030
MAR 2005
Ver.2.1
DP-2310/3010
15 Not Used
16 Side Adjust (ADU) Adjustment of LSU side-side (ADU). -8 - +7
0.5mm
17 Charge Roller Voltage Charge voltage compensation adjustment. -76 - +76
2.60V
18 Standard Laser Power Laser power compensation adjustment. -29 - +25
19 Std Bias DC Voltage Adjustment of bias standard voltage. -77 - 76
3.92V
20 Not Used
21 TDC Gain Voltage Adjustment of toner density sensor gain
voltage.
-86 - +40
0.033V
22-24 Not Used
25 Bias Duty Ratio
(Factory use only)
Bias duty ratio adjustment -5 - +5
0.80%
26 TDC Judgment Level Adjustment of toner supply starting judgement
voltage level.
-26 - +26
19.5mV
27 Bias Frequency
(Factory use only)
AC Bias frequency adjustment -5 - +3
28 QUANTUM White Density Adjustment of standard white density level. -99 - +99
29 QUANTUM Black Density Adjustment of standard black density level. -99 - +99
30 Light Halftone Adj. Halftone duty ratio adjustment -127 - +127
31 Fuser Temperature Adjustment of fuser temperature. -15 - +15
0.833°C
32 Fuser Edge Temperature Temperature compensation for edges -15 - +15
0.833°C
33 TDC Max. Read Only Set by Digital QUANTUM (QUARC) control -99 - +99
(Read only)
34 TDC Min. Read Only Set by Digital QUANTUM (QUARC) control -99 - +99
(Read only)
35 TDC Avg. Read Only Set by Digital QUANTUM (QUARC) control -99 - +99
(Read only)
36 Paper Loop (Tray 1) Individual Fine Adjustment for Tray 1 -99 - +99
37 Not Used
38 ID Standard Voltage Adjustment of judgement standard voltage. -35 - +35
39 LSU Unit PWM Adjust Adjustment of PWM value of LSU. -32 - +32
40 Transfer Current Side 1 Adjustment of Transfer Current. -16 - +15
0.6uA
41 Paper Loop (Bypass) Individual Fine Adjustment for Sheet Bypass -99 - +99
42 Paper Loop (Tray 2) Individual Fine Adjustment for Tray 2 -99 - +99
43 Paper Loop (2-Sided) Adjustment for the length of the loop formed
before the copier timing roller.
-99 - +99
44 FAX Laser Duty Adj Printer Density Adjustment for FAX.
(-) : Darker.
(+) : Lighter.
-99 - +99
45 Not Used
46 PRINTER Laser Duty Adj Printer Density Adjustment for Printer.
(-) : Darker.
(+) : Lighter.
-99 - +99
F6 Mode
No. Item Remarks
Setting
Range
