Panasonic DP-2330

195
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
47 Transfer Current Side 2 Adjustment of Transfer Current. -16 - +15
0.6uA
48 Not Used
49 T Mode Image Density Image density adjustment for Text mode.
(-) : Darker.
(+) : Lighter.
-99 - +99
50 T/P Mode Image Density Image density adjustment for Text/ Photo
mode.
(-) : Darker.
(+) : Lighter.
-99 - +99
51 P Mode Image Density Image density adjustment for Photo mode.
(-) : Darker.
(+) : Lighter.
-99 - +99
52 Not Used
53 CCD Read Position Adj Adjustment of CCD read position. -42 - +44
0.2mm
54 T Mode Contrast Adjustment of Contrast for Text Mode. -128 - +127
55 T/P Mode Contrast Adjustment of Contrast for Text/Photo Mode. -128 - +127
56 P Mode Contrast Adjustment of Contrast for Photo Mode. -128 - +127
57 Charge Roller Frequency Adjustment of Charge Roller Frequency. -56 - +25
58 Charge Roller Current Adjustment of Charge Roller Current. -58 - 0
5uA
59 Trail Edge Trans Trays Trail Edge Transfer Image High Voltage
Timing Adjustment for Trays 1-4 feeding.
-30 - +30
0.5mm
60 Trail Edge Trans Bypass Trail Edge Transfer Image High Voltage
Timing Adjustment for Bypass Tray feeding.
-30 - +30
0.5mm
61 Trail Edge Trans 2Sided Trail Edge Transfer Image High Voltage
Timing Adjustment for the 2nd side of 2-Sided
printing.
-30 - +30
0.5mm
62 TDC Gain Voltage Adjust Adjustment of Toner Density sensor gain
voltage.
-10 - +10
0.033V
63 Lead Edge Read Timing Adjustment of Lead Edge Read Point. 0 - +9
0.5mm
64 Side Edge Read Adjust Adjustment of Side Edge Read Point. 0 - +9
0.5mm
65 Black Density Reference Reference voltage for Black Density sensor. -127 - +127
66 Black Density Output Compensate value for Black Density sensor
output.
-127 - +127
67 ADF Image Density Compensation of ADF image density. -99 - +99
68 Paper Loop (Tray 3) Individual Fine Adjustment for Tray 3 -99 - +99
69 Stamp Position Adjust Adjustment of verification stamp position. -50 - +50
0.3mm
70-77 Not Used
78 Paper Loop (Tray 4) Individual Fine Adjustment for Tray 4 -99 - +99
79 MTF Adjust Adjustment of Scanning Sharpness by digital
image processing for Text /Photo Copy Mode.
-2 - +2
80 QUANTUM Photo Mode Read Value of QUANTUM Gamma Table for Photo
Mode.
+1 - +5
(Read Only)
F6 Mode
No. Item Remarks
Setting
Range
