087 ADU Intermediate Roller Clutch When SPC PCB CN711-2 signal
level changes to 0V from +24V, the
Clutch operates.
088-
099
Not Used
100 Inner Upper Paper Exit Solenoid When SPC PCB CN719-3 signal
level changes to 0V from +24V, the
clutch turns OFF.
101 Inner Lower Paper Exit Solenoid When SPC PCB CN719-1 signal
level changes to 0V from +24V, the
clutch turns.
102 Paper Transport Unit Motor
(Exit to Outer Tray)
Paper transport unit motor rotates in
the forward direction.
103 Paper Transport Unit Motor
(Exit to ADU)
Paper transport unit motor rotates in
the reverse direction.
104 Paper Guide Solenoid ON When EXFD PCB CN792-1 signal
level changes to 0V from +24V,
clutch turns ON for Straight Paper
Exit.
105 Paper Guide Solenoid OFF When EXFD PCB CN792-3 signal
level changes to 0V from +24V,
clutch turns OFF for Inverting Paper
Exit.
106-
109
Not Used
110 Paper Feed Motor Feed Motor rotates. 1-Bin Finisher (FS300).
Paper Alignment Motor Paper Alignment Motor drives the
Alignment Plate.
Paper Tray Lift Motor Paper Tray Lift Motor drives the
Paper Tray up and down.
Stapler Motor Stapler Motor rotates 2 sec. cycle.
Paddle Solenoid Solenoid turns ON/OFF 500 msec.
cycle.
Large Gear Solenoid Solenoid turns ON/OFF 500 msec.
cycle.
Paper Hold Lever Solenoid Solenoid turns ON/OFF 1 sec. cycle.
111-
119
Not Used
120 Lamp When SDR PCB CN656-1 signal
level changes to 0V from +5V, Lamp
operates.
121-
159
Not Used
160 ADF Paper Feed Motor Rotating
(35% speed rotating)
ADF paper feed motor rotates at
35% speed.
161 ADF Paper Feed Motor Rotating
(100% speed rotating)
ADF paper feed motor rotates at
100% speed.
162 ADF Paper Feed Motor Rotating
(400% speed rotating)
ADF paper feed motor rotates at
400% speed.
F4 Mode (Output Check)
No. Item Function Remark
