385
DP-2330/3030
MAR 2005
Ver. 2.1
DP-2310/3010
(18) Remove the OPC Drum Shaft Holder
Assembly.
(19) Remove the Front DSD Arm.
(20) Lift the OPC Drum, holding the right side where
the OPC Drum Shaft Holder Assembly was
installed.
(21) Clean the Bias Charge Roller with a soft dry cloth
that came with the new OPC Drum.
(22) Insert 2 LTR (A4) size papers (brand new)
under the Bias Charge Roller passing through
the Discharge Light slit as illustrated.
Note:
The width of the paper should cover the entire
width of the Bias Charge Roller.
(23) Lift both sides of the papers and cover the Bias
Charge Roller, then place the OPC Drum Shaft
Holder on top of the papers to act as a weight.
To Next Page
