P series User Guide 209
0x220C
Digital Input Signal 13 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x0016
-
RW
No
Power
Resupply
Yes
Set the function of I/O connector‘s digital input signal 13 and input signal level.
Please see the descriptions 0x2200 for more detailed explanation.
0x220D
Digital Input Signal 14 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x0017
-
RW
No
Power
Resupply
Yes
Set the function of I/O connector‘s digital input signal 14 and input signal level.
Please see the descriptions 0x2200 for more detailed explanation.
0x220E
Digital Input Signal 15 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x0018
-
RW
No
Power
Resupply
Yes
Set the function of I/O connector‘s digital input signal 15 and input signal level.
Please see the descriptions 0x2200 for more detailed explanation.
0x220F
Digital Input Signal 16 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x0019
-
RW
No
Power
Resupply
Yes
Set the function of I/O connector‘s digital input signal 16 and input signal level.
Please see the descriptions 0x2200 for more detailed explanation.
0x2210
Digital Output Signal 1 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x8002
-
RW
No
Power
Resupply
Yes
Allocates the function of I/O connector‘s digital output signal 1, and sets the output
signal level.
Example) when the set value is 0x8001.
