Parker PD-04 Series

Parker Hannifin
P series User Guide 214
0x2223
Analog Monitor Channel 1 Offset
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
DINT
0 to 0x40000000
0
-
RW
No
At all
times
Yes
Subtracts the set offset value from the monitoring variable set for monitor output
channel 1, and outputs the value. The unit is the unit of the variable set at analog
monitor channel 1 setting (0x2221).
0x2224
Analog Monitor Channel 2 Offset
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
DINT
0 to 0x40000000
0
-
RW
No
At all
times
Yes
Subtracts the set offset value from the monitoring variable set for monitor output
channel 2, and outputs the value. The unit is the unit of the variable set at analog
monitor channel 2 setting (0x2222).
0x2225
Analog Monitor Channel 1 Scale
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UDINT
0 to 0x40000000
500
-
RW
No
At all
times
Yes
Sets the scaling of variables to output per 1V when outputting the monitoring
variables set for analog monitor output channel 1..The unit is the unit/1V of the
variable set at analog monitor channel 1 setting (0x2221).
For example, by setting the speed feedback to channel 1 and set the scale to 500,
up to +/-5000rpm can be output at +/-10V.
0x2226
Analog Monitor Channel 2 Scale
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UDINT
0 to 0x40000000
500
-
RW
No
At all
times
Yes
Set the scaling of variables to output per 1V when outputting the monitoring
variables set for analog monitor output channel 2. The unit is the unit/1V of the
variable set at analog monitor channel 2 setting (0x2222).
