Parker PD-04 Series

Parker Hannifin
P series User Guide 217
0x230B
Program Jog Operation Time 4
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 10000
5000
ms
RW
No
At all
times
Yes
Please see descriptions on speed 1(0x2304).
0x230C
Index Pulse Search Speed
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
INT
-1000 to 1000
20
rpm
RW
No
Servo Off
Yes
Set the index pulse search speed.
0x230D
Speed Limit Function Select
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 3
0
-
RW
No
Servo Off
Yes
Set the speed limit function for torque control.
Set Value
Setting Details
0
Limited to the limit speed value (0x230E)
1
Limited to the motor‘s maximum speed
0x230E
Speed Limit Value at Torque Control Mode
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 6000
1000
rpm
RW
Yes
At all
times
Yes
Set the limit speed value for torque control. It only applies when the speed limit function
setting (0x230D) is set to 0.
0x230F
Over Speed Detection Level
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 10000
6000
rpm
RW
No
At all
times
Yes
Sets the detection level for the excessive speed alarm (AL-50).When the set value is
higher than the motor‘s maximum speed, the detection level is determined by the
motor‘s maximum speed
