Parker PD-04 Series

Parker Hannifin
P series User Guide 221
Set Value
Setting Details
0
Do not use Modulo function
1
Move forward using Modulo function
2
Move reverse using Modulo function
3
Mote in the direction of the shortest distance using Modulo
function
0x240C
Modulo Factor
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
DINT
1 to 0x3FFFFFFF
3600
UU
RW
No
Servo Off
Yes
Set the Modulo factor. Set the position value corresponding to 1 rotation when the
user drives the motor.
0x240D
User Drive Name
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
STRIN
G
-
‗Drive‘
UU
RW
No
Servo Off
Yes
The user can define the drive name up to 16 characters.
0x240E
Individual Parameter Store
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 1
0
-
RW
No
At all
times
No
Select whether to store the parameters individually. This parameter is not stored,
and goes back to 0 when the power is turned on.
Set Value
Setting Details
0
Do not individually store parameters. See parameter store
0x1010) for parameters storing.
1
Individually store parameters. Parameters are automatically
stored.
 Enhanced Control(0x2500~ )
0x2500
Adaptive Filter Function Select
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 5
0
-
RW
No
Servo Off
Yes
Set the function of adaptive filter.
