User’s Manual of WGSW-20160HP/WGSW-24040HP series
Figure 4-5-3: Aggregation Group Configuration Page Screenshot
The Page includes the following fields:
.Object Description
• Group ID
Indicates the group ID for the settings contained in the same row. Group ID
"Normal" indicates there is no aggregation. Only one group ID is valid per port.
• Port Members
Each switch port is listed for each group ID. Select a radio button to include a port
in an aggregation, or clear the radio button to remove the port from the
aggregation. By default, no ports belong to any aggregation group.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
