User’s Manual of WGSW-20160HP/WGSW-24040HP series
311
Port Policies Configuration
Every port may advertise a unique set of network policies or different attributes for the same network policies, based on the
authenticated user identity or port configuration.
Object Description
• Port
The port number for which the configuration applies.
• Policy ID
The set of policies that shall apply for a given port. The set of policies is selected
by checkmarking the checkboxes that corresponds to the policies
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.14.4 LLDP-MED Neighbor
This Page provides a status overview for all LLDP-MED neighbors. The displayed table contains a row for each port on which an
LLDP neighbor is detected. The LLDP-MED Neighbor Information screen in Figure 4-14-3 appears. The columns hold the
following information:
Figure 4-14-3: LLDP-MED Neighbor Information Page Screenshot
The Page includes the following fields:
Fast start repeat count
Object Description
• Port
The port on which the LLDP frame was received.
• Device Type
LLDP-MED Devices are comprised of two primary Device Types: Network
Connectivity Devices and Endpoint Devices.
LLDP-MED Network Connectivity Device Definition
LLDP-MED Network Connectivity Devices, as defined in TIA-1057, provide
