User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.10.5 ACL Rate Limiter Configuration
Configure the rate limiter for the ACL of the switch.
The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears.
Figure 4-10-5: ACL Rate Limiter Configuration Page Screenshot
The Page includes the following fields:
Object Description
• Rate Limiter ID
The rate limiter ID for the settings contained in the same row.
• Rate
The allowed values are: 0-3276700 in pps or 0, 100, 200, 300, ..., 1000000 in
kbps.
• Unit
Specify the rate unit. The allowed values are:
pps: packets per second.
kbps: Kbits per second.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
