User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.9.2 Port Policing
This Page allows you to configure the Policer settings for all switch ports. The Port Policing screen in Figure 4-9-1 appears.
Figure 4-9-1: QoS Ingress Port Policers Page Screenshot
The Page includes the following fields:
Object Description
• Port
The port number for which the configuration below applies.
• Enable
Controls whether the policer is enabled on this switch port.
• Rate
Controls the rate for the policer. The default value is 500. This value is restricted
to 100-1000000 when the "Unit" is "kbps" or "fps", and it is restricted to 1-3300
when the "Unit" is "Mbps" or "kfps".
• Unit
Controls the unit of measure for the policer rate as kbps, Mbps, fps or kfps . The
default value is "kbps".
• Flow Control
If flow control is enabled and the port is in flow control mode, then pause frames
are sent instead of discarding frames.
