User’s Manual of WGSW-20160HP/WGSW-24040HP series
281
4.12.3 Access Management Statistics
This Page provides statistics for access management. The Access Management Statistics screen in Figure 4-12-3 appears.
Figure 4-12-3: Access Management Statistics Overview Page Screenshot
The Page includes the following fields:
Object Description
• Interface
The interface that allowed remote host can access the switch.
• Receive Packets
The received packets number from the interface under access management
mode is enabled.
• Allow Packets
The allowed packets number from the interface under access management
mode is enabled.
• Discard Packets
The discarded packets number from the interface under access management
mode is enabled.
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Clear all statistics.
