User’s Manual of WGSW-20160HP/WGSW-24040HP series
172
4.8.5 IGMP Snooping Status
This Page provides IGMP Snooping status. The IGMP Snooping Status screen in Figure 4-8-8 appears.
Figure 4-8-8: IGMP Snooping Status Page Screenshot
The Page includes the following fields:
Object Description
• VLAN ID
The VLAN ID of the entry.
• Querier Version
Working Querier Version currently.
• Host Version
Working Host Version currently.
• Querier Status
Show the Querier status is "ACTIVE" or "IDLE".
• Querier Transmitted
The number of Transmitted Querier.
• Querier Received
The number of Received Querier.
• V1 Reports Received
The number of Received V1 Reports.
• V2 Reports Received
The number of Received V2 Reports.
