User’s Manual of WGSW-20160HP/WGSW-24040HP series
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.9.3 Port Classification
This Page allows you to configure the basic QoS Ingress Classification settings for all switch ports. The Port Classification
screen in Figure 4-9-2 appears.
Figure 4-9-2 : QoS Ingress Port Classification Page Screenshot
The Page includes the following fields:
Object Description
• Port
The port number for which the configuration below applies.
• QoS Class
Controls the default QoS class, i.e., the QoS class for frames not classified in any
other way. There is a one to one mapping between QoS class, queue and priority.
