User’s Manual of WGSW-20160HP/WGSW-24040HP series
A QoS class of 0 (zero) has the lowest priority.
Note: If the QoS class has been dynamically changed, then the actual QoS class
is shown in parentheses after the configured QoS class.
• DP Level
Controls the default Drop Precedence Level, i.e., the DP level for frames not
classified in any other way.
• PCP
Controls the default PCP for untagged frames.
• DEI
Controls the default DEI for untagged frames.
• Tag Class.
Shows the classification mode for tagged frames on this port.
Disabled: Use default QoS class and DP level for tagged frames.
Enabled: Use mapped versions of PCP and DEI for tagged frames.
Click on the mode in order to configure the mode and/or mapping.
• DSCP Based
Click to Enable DSCP Based QoS Ingress Port Classification.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
