User’s Manual of WGSW-20160HP/WGSW-24040HP series
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
4.7.4 CIST Port Configuration
This Page allows the user to inspect the current STP CIST port configurations, and possibly change them as well. The CIST
Port Configuration screen in Figure 4-7-6 appears.
Figure 4-7-6 : STP CIST Port Configuration Page Screenshot
The Page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port.
• STP Enabled
Controls whether RSTP is enabled on this switch port.
• Path Cost
Controls the path cost incurred by the port. The Auto setting will set the path cost
