User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.6.13 IP Subnet-based VLAN
The IP subnet-based VLAN enties can be configured here. This Page allows for adding, updating and deleting IP subnet-based
VLAN entries and assigning the entries to different ports. This Page shows only static entries. The IP-based VLAN screen in
Figure 4-6-19 appears.
Figure 4-6-19: Protocol to Group Mapping Table Page Screenshot
The Page includes the following fields:
Object Description
• Delete
To delete a Protocol to Group Name map entry, check this box. The entry will be
deleted on the switch during the next Save.
• VCE ID
Indicates the index of the entry. It is user configurable. It's value ranges from
0-256. If a VCE ID is 0, application will auto-generate the VCE ID for that entry.
Deletion and lookup of IP subnet-based VLAN are based on VCE ID.
• IP Address
Indicates the IP address.
• Mask Length
Indicates the network mask length.
• VLAN ID
Indicates the VLAN ID. VLAN ID can be changed for the existing entries.
• Port Members
A row of check boxes for each port is displayed for each IP subnet-based VLAN
entry. To include a port in a IP subnet-based VLAN, check the box. To remove or
exclude the port from the IP subnet-based VLAN, make sure the box is
unchecked. By default, no ports are members, and all boxes are unchecked.
• Adding a New IP
subnet-based VLAN
Click “Add New Entry” to add a new IP subnet-based VLAN entry. An empty row
is added to the table, and the IP subnet-based VLAN entry can be configured as
needed. Any IP address/mask can be configured for the IP subnet-based VLAN
entry. Legal values for a VLAN ID are 1 through 4095.
The IP subnet-based VLAN entry is enabled when you click on "Save". The
“Delete: button can be used to undo the addition of new IP subnet-based VLANs.
