User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.12.11 IP Source Guard Static Table
This Page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11 appears.
Figure 4-12-11: Static IP Source Guard Table Screen Page Screenshot
The Page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Port
The logical port for the settings.
• VLAN ID
The VLAN ID for the settings.
• IP Address
Allowed Source IP address.
• MAC Address
Allowed Source MAC address.
Buttons
: Click to add a new entry to the Static IP Source Guard table.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
