User’s Manual of WGSW-20160HP/WGSW-24040HP series
• Port Shaper Enable
Controls whether the port shaper is enabled for this switch port.
• Port Shaper Rate
Controls the rate for the port shaper. The default value is 500. This value is
restricted to 100-1000000 when the "Unit" is "kbps", and it is restricted to
1-13200 when the "Unit" is "Mbps".
• Port Shaper Unit
Controls the unit of measure for the port shaper rate as "kbps" or "Mbps". The
default value is "kbps".
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
: Click to undo any changes made locally and return to the previous Page.
4.9.6 Port Tag Remarking
This Page provides an overview of QoS Egress Port Tag Remarking for all switch ports. The Port Tag Remarking screen in
Figure 4-9-6 appears.
Figure 4-9-6: QoS Egress Port Tag Remarking Page Screenshot
