User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.18.4 RMON Event Configuration
Configure RMON Event table on this Page. The entry index key is ID; screen in Figure 4-18-4 appears.
Figure 4-18-4: RMON Event Configuration Page Screenshot
The Page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• ID
Indicates the index of the entry. The range is from 1 to 65535.
• Desc
Indicates this event, the string length is from 0 to 127, default is a null string.
• Type
Indicates the notification of the event, the possible types are:
none: The total number of octets received on the interface, including framing
characters.
log: The number of uni-cast packets delivered to a higher-layer protocol.
snmptrap: The number of broad-cast and multi-cast packets delivered to a
higher-layer protocol.
logandtrap: The number of inbound packets that are discarded even the
packets are normal.
• Community
Specify the community when trap is sent, the string length is from 0 to 127,
default is "public".
• Event Last Time
Indicates the value of sysUpTime at the time this event entry last generated an
event.
Buttons
: Click to add a new community entry.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
