User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.12.13 ARP Inspection Static Table
This Page provides Static ARP Inspection Table. The Static ARP Inspection Table screen in Figure 4-12-13 appears.
Figure 4-12-13: Static ARP Inspection Table Screen Page Screenshot
The Page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Port
The logical port for the settings.
• VLAN ID
The VLAN ID for the settings.
• MAC Address
Allowed Source MAC address in ARP request packets.
• IP Address
Allowed Source IP address in ARP request packets.
Buttons
: Click to add a new entry to the Static ARP Inspection table.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
