User’s Manual of WGSW-20160HP/WGSW-24040HP series
• Oversize
The total number of packets received that were longer than 1518 octets.
• Fragements
The number of frames which size is less than 64 octets received with invalid
CRC.
• Jabb.
The number of frames which size is larger than 64 octets received with invalid
CRC.
• Collision
The best estimate of the total number of collisions on this Ethernet segment.
• 64 Bytes
The total number of packets (including bad packets) received that were 64 octets
in length.
• 65~127 Bytes
The total number of packets (including bad packets) received that were between
65 to 127 octets in length.
• 128~255 Bytes
The total number of packets (including bad packets) received that were between
128 to 255 octets in length.
• 256~511 Bytes
The total number of packets (including bad packets) received that were between
256 to 511 octets in length.
• 512~1023 Bytes
The total number of packets (including bad packets) received that were between
512 to 1023 octets in length.
• 1024~1518 Bytes
The total number of packets (including bad packets) received that were between
1024 to 1518 octets in length.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
4.18.12 RMON Statistics Status
This Page provides an overview of RMON Statistics entries. Each Page shows up to 99 entries from the Statistics table, default
being 20, selected through the "entries per Page" input field. When first visited, the web Page will show the first 20 entries from
the beginning of the Statistics table. The first displayed will be the one with the lowest ID found in the Statistics table; screen in
Figure 4-18-12 appears.
Figure 4-18-12: RMON Statistics Status Overview Page Screenshot
