User’s Manual of WGSW-20160HP/WGSW-24040HP series
The Page includes the following fields:
Object Description
• ID
Indicates the index of Statistics entry.
• Data Source (ifIndex)
The port ID which wants to be monitored.
• Drop
The total number of events in which packets were dropped by the probe due to
lack of resources.
• Octets
The total number of octets of data (including those in bad packets) received on
the network.
• Pkts
The total number of packets (including bad packets, broadcast packets, and
multicast packets) received.
• Broadcast
The total number of good packets received that were directed to the broadcast
address.
• Multicast
The total number of good packets received that were directed to a multicast
address.
• CRC Errors
The total number of packets received that had a length (excluding framing bits,
but including FCS octets) of between 64 and 1518 octets.
• Undersize
The total number of packets received that were less than 64 octets.
• Oversize
The total number of packets received that were longer than 1518 octets.
• Frag.
The number of frames which size is less than 64 octets received with invalid
CRC.
• Jabb.
The number of frames which size is larger than 64 octets received with invalid
CRC.
• Coll.
The best estimate of the total number of collisions on this Ethernet segment.
• 64 Bytes
The total number of packets (including bad packets) received that were 64 octets
in length.
• 65~127
The total number of packets (including bad packets) received that were between
65 to 127 octets in length.
• 128~255
The total number of packets (including bad packets) received that were between
128 to 255 octets in length.
• 256~511
The total number of packets (including bad packets) received that were between
256 to 511 octets in length.
• 512~1023
The total number of packets (including bad packets) received that were between
512 to 1023 octets in length.
• 1024~1518
The total number of packets (including bad packets) received that were between
1024 to 1518 octets in length.
