User’s Manual of WGSW-20160HP/WGSW-24040HP series
lack of resources.
• Octets
The total number of octets of data (including those in bad packets) received on
the network.
• Pkts
The total number of packets (including bad packets, broadcast packets, and
multicast packets) received.
• Broadcast
The total number of good packets received that were directed to the broadcast
address.
• Multicast
The total number of good packets received that were directed to a multicast
address.
• CRC/Alignment
The total number of packets received that had a length (excluding framing bits,
but including FCS octets) of between 64 and 1518 octets.
• Undersize
The total number of packets received that were less than 64 octets.
• Oversize
The total number of packets received that were longer than 1518 octets.
• Fragments
The number of frames which size is less than 64 octets received with invalid
CRC.
• Jabber
The number of frames which size is larger than 64 octets received with invalid
CRC.
• Collisions
The best estimate of the total number of collisions on this Ethernet segment.
• Utilization
The best estimate of the mean physical layer network utilization on this interface
during this sampling interval, in hundredths of a percent.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
4.18.9 RMON History Status
This Page provides an overview of RMON History entries. Each Page shows up to 99 entries from the History table, default
being 20, selected through the "entries per Page" input field. When first visited, the web Page will show the first 20 entries from
the beginning of the History table. The first displayed will be the one with the lowest History Index and Sample Index found in the
History table; screen in Figure 4-18-9 appears.
