User’s Manual of WGSW-20160HP/WGSW-24040HP series
The Page includes the following fields:
Object Description
• Snooping Mode
Indicates the DHCP snooping mode operation. Possible modes are:
Enabled: Enable DHCP snooping mode operation. When enable DHCP
snooping mode operation, the request DHCP messages will be forwarded to
trusted ports and only allowed reply packets from trusted ports.
Disabled: Disable DHCP snooping mode operation.
• Port Mode
Configuration
Indicates the DHCP snooping port mode. Possible port modes are:
Trusted: Configures the port as trusted sources of the DHCP message.
Untrusted: Configures the port as untrusted sources of the DHCP message.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.12.9 DHCP Snooping Statistics
This Page provides statistics for DHCP snooping. The statistics only counter packet under DHCP snooping mode is enabled
and relay mode is disabled. And it doesn't count the DHCP packets for system DHCP client. The DHCP Snooping Port Statistics
screen in Figure 4-12-9 appears.
Figure 4-12-9: DHCP Snooping Port Statistics Screen Page Screenshot
