User’s Manual of WGSW-20160HP/WGSW-24040HP series
The Page includes the following fields:
Object Description
• Rx and Tx Discover
The number of discover (option 53 with value 1) packets received and
transmitted.
• Rx and Tx Offer
The number of offer (option 53 with value 2) packets received and transmitted.
• Rx and Tx Request
The number of request (option 53 with value 3) packets received and transmitted.
• Rx and Tx Decline
The number of decline (option 53 with value 4) packets received and transmitted.
• Rx and Tx ACK
The number of ACK (option 53 with value 5) packets received and transmitted.
• Rx and Tx NAK
The number of NAK (option 53 with value 6) packets received and transmitted.
• Rx and Tx Release
The number of release (option 53 with value 7) packets received and transmitted.
• Rx and Tx Inform
The number of inform (option 53 with value 8) packets received and transmitted.
• Rx and Tx Lease Query
The number of lease query (option 53 with value 10) packets received and
transmitted.
• Rx and Tx Lease
Unassigned
The number of lease unassigned (option 53 with value 11) packets received and
transmitted.
• Rx and Tx Lease
Unknown
The number of lease unknown (option 53 with value 12) packets received and
transmitted.
• Rx and Tx Lease
Active
The number of lease active (option 53 with value 13) packets received and
transmitted.
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Clears the counters for the selected port.
