User’s Manual of WGSW-20160HP/WGSW-24040HP series
4.14.6 Port Statistics
This Page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to
the whole stack, switch, while local counters refers to counters for the currently selected switch. The LLDP Statistics screen in
Figure 4-14-5 appears.
Figure 4-14-5: LLDP Statistics Page Screenshot
The Page includes the following fields:
Global Counters
Object Description
• Neighbor entries were
last changed
It also shows the time when the last entry was last deleted or added. It also
shows the time elapsed since the last change was detected.
• Total Neighbors
Entries Added
Shows the number of new entries added since switch reboot.
• Total Neighbors
Entries Deleted
Shows the number of new entries deleted since switch reboot.
• Total Neighbors
Entries Dropped
Shows the number of LLDP frames dropped due to that the entry table was full.
• Total Neighbors
Entries Aged Out
Shows the number of entries deleted due to Time-To-Live expiring.
