1.5 Product Specifications
Product WGSW-20160HP
Hardware Specification
Copper Ports 16 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
10/100/1000Mbps / SFP Combo
Interfaces
4 10/100/1000Mbps TP and SFP shared combo interfaces, SFP(Mini-GBIC) supports
100/1000Mbps Dual mode, shared with Port-17 to Port-20
Console 1 x RS-232 DB9 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 40Gbps / non-blocking
Throughput 29.7Mpps@64Bytes
Address Table 8K entries, automatic source address learning and ageing
Share Data Buffer 4 megabits
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
Dimensions (W x D x H)
440 x 300 x 44.5 mm, 1U high
Weight
4.1kg
LED
System:
Power (Green), SYS (System, Green).
Alert:
FAN1 (Green), FAN2 (Green)
PoE Ethernet Interfaces (Port 1 to Port 16):
LNK/ACT (10/100/1000Mbps, Green), PoE In-Use (Orange)
10/100/1000Base-T Combo Ports (Port 17 to Port 20):
1000 (LNK/ACT, Green), 10/100 (LNK/ACT, Orange)
100/1000Mbps SFP Combo Interfaces(Port 17 to Port 20):
1000 (LNK/ACT, Green), 100 (LNK/ACT, Orange)t
Power Requirements
100~240V AC, 50/60Hz, 2A
Power Consumption
Max. 22 watts / 75BTU
ESD Protection
6KV DC
Power over Ethernet
PoE Standard
IEEE 802.3af / 802.3at PoE / PSE
PoE Power Supply Type
End-Span
PoE Power Output
56V DC per port
Max. 30.8 watts
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget
Max. 230 watts
PoE Ability
Number of PD @ 7
16

Planet WGSW-20160HP Specifications

General

Brand	Planet
Model	WGSW-20160HP
Category	Switch
Language	English
