User’s Manual of WGSW-20160HP/WGSW-24040HP series
29
Watts
Number of PD @
15.4 Watts
14
Number of PD @
30.8 Watts
7
Layer 2 Management Function
Basic Management Interfaces Console, Telnet, Web Browser, SNMP v1, v2c
Secure Management Interfaces SSH, SSL, SNMP v3
Port Configuration
Port disable / enable
Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Port Status
Display each port’s speed duplex mode, link status, flow control status, a
uto negotiation
status, trunk status
Port Mirroring
TX / RX / Both
Many-to-1 monitor
VLAN
802.1Q Tagged Based VLAN, up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-Based VLAN
Protocol-Based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4094 VLAN IDs
Link Aggregation
IEEE 802.3ad LACP / Static Trunk
Support 10 groups of 16-Port trunk support
QoS
Traffic classification based, Strict priority and WRR
8-Level priority for switching
- Port Number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/TOS field in IP Packet
IGMP Snooping
IGMP (v1/v2/v3) Snooping, up to 255 multicast Groups
IGMP Querier mode support
MLD Snooping
MLD (v1/v2) Snooping, up to 255 multicast Groups
MLD Querier mode support
Access Control List
IP-Based ACL / MAC-Based ACL
Up to 256 entries
Bandwidth Control
Per port bandwidth control
Ingress: 500Kb~80Mbps
Egress: 64Kb~80Mbps
SNMP MIBs
RFC-1213 MIB-II
IF-MIB
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB
RFC-2819 RMON MIB (Group 1, 2, 3 and 9)
RFC-2737 Entity MIB
