User’s Manual of WGSW-20160HP/WGSW-24040HP series
This Page provides MVR related configuration. The MVR screen in Figure 4-8-17 appears.
Figure 4-8-17: MVR Configuration Page Screenshot
The Page includes the following fields:
Object Description
• MVR Mode
Enable/Disable the Global MVR.
The Unregistered Flooding control depends on the current configuration in
IGMP/MLD Snooping.
It is suggested to enable Unregistered Flooding control when the MVR group
table is full.
• Delete
Check to delete the entry. The designated entry will be deleted during the next
save.
• MVR VID
Specify the Multicast VLAN ID.
