User’s Manual of WGSW-20160HP/WGSW-24040HP series
The Page includes the following fields:
Object Description
• DSCP
Maximum number of supported DSCP values are 64 and valid DSCP value
ranges from 0 to 63.
• Ingress
Ingress side DSCP can be first translated to new DSCP before using the DSCP
for QoS class and DPL map.
There are two configuration parameters for DSCP Translation -
Translate
Classify
• Translate
DSCP at Ingress side can be translated to any of (0-63) DSCP values.
• Classify
Click to enable Classification at Ingress side.
• Egress
There is following configurable parameter for Egress side -
Remap
• Remap DP0
Select the DSCP value from select menu to which you want to remap. DSCP
value ranges form 0 to 63.
• Remap DP1
Select the DSCP value from select menu to which you want to remap. DSCP
value ranges form 0 to 63.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
To Next Page
