User’s Manual of WGSW-20160HP/WGSW-24040HP series
209
DSCP Diffserv Code Point value(DSCP): It can be specific value, range of value
or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7, EF or
AF11-AF43
IP Fragment IPv4 frame fragmented option: yes|no|any
Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range applicable
for IP protocol UDP/TCP
Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
• IPv6
Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
Source IP IPv6 source address: (a.b.c.d) or 'Any', 32 LS bits
DSCP Diffserv Code Point value(DSCP): It can be specific value, range of value
or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7, EF or
AF11-AF43
Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range applicable
for IP protocol UDP/TCP
Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
• Action Parameters
Class QoS class: (0-7) or 'Default'.
DPL Valid Drop Precedence Level can be (0-3) or 'Default'.
DSCP Valid DSCP value can be (0-63, BE, CS1-CS7, EF or AF11-AF43) or
'Default'.
'Default' means that the default classified value is not modified by this QCE.
Buttons
: Click to save the configuration and move to main QCL Page
: Click to undo any changes made locally and revert to previously saved values
: Return to the previous Page without saving the configuration change
