User’s Manual of WGSW-20160HP/WGSW-24040HP series
• Mirror
Specify the mirror operation of this port. Frames matching the ACE are mirrored
to the destination mirror port. The allowed values are:
Enabled: Frames received on the port are mirrored.
Disabled: Frames received on the port are not mirrored.
The default value is "Disabled".
• Counter
The counter indicates the number of times the ACE was hit by a frame.
• Modification Buttons
You can modify each ACE (Access Control Entry) in the table using the following
buttons:
: Inserts a new ACE before the current row.
: Edits the ACE row.
: Moves the ACE up the list.
: Moves the ACE down the list.
: Deletes the ACE.
: The lowest plus sign adds a new entry at the bottom of the ACE listings.
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page; any changes made locally will be undone.
: Click to clear the counters.
: Click to remove all ACEs.
