User’s Manual of WGSW-20160HP/WGSW-24040HP series
The Page includes the following fields:
Object Description
• Port
The switch port number. Click to navigate to detailed NAS statistics for this port.
• Admin State
The port's current administrative state. Refer to NAS Admin State for a
description of possible values.
• Port State
The current state of the port. Refer to NAS Port State for a description of the
individual states.
• Last Source
The source MAC address carried in the most recently received EAPOL frame for
EAPOL-based authentication, and the most recently received frame from a new
client for MAC-based authentication.
• Last ID
The user name (supplicant identity) carried in the most recently received
Response Identity EAPOL frame for EAPOL-based authentication, and the
source MAC address from the most recently received frame from a new client for
MAC-based authentication.
• QoS Class
QoS Class assigned to the port by the RADIUS server if enabled.
• Port VLAN ID
The VLAN ID that NAS has put the port in. The field is blank, if the Port VLAN ID
is not overridden by NAS.
If the VLAN ID is assigned by the RADIUS server, "(RADIUS-assigned)" is
appended to the VLAN ID. Read more about RADIUS-assigned VLANs here.
If the port is moved to the Guest VLAN, "(Guest)" is appended to the VLAN ID.
Read more about Guest VLANs here.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
