User’s Manual of WGSW-20160HP/WGSW-24040HP series
250
Port Counters
Object Description
• EAPOL Counters
These supplicant frame counters are available for the following administrative states:
Force Authorized
Force Unauthorized
Port-based 802.1X
Single 802.1X
Multi 802.1X
Direction Name IEEE Name Description
Rx Total dot1xAuthEapolFrames
Rx
The number of valid EAPOL
frames of any type that have
been received by the switch.
Rx Response ID dot1xAuthEapolRespId
FramesRx
The number of valid EAPOL
Response Identity frames
that have been received by
the switch.
Rx Responses dot1xAuthEapolRespFr
amesRx
The number of valid EAPOL
response frames (other than
Response Identity frames)
that have been received by
the switch.
Rx Start dot1xAuthEapolStartFra
mesRx
The number of EAPOL Start
frames that have been
received by the switch.
Rx Logoff dot1xAuthEapolLogoffFr
amesRx
The number of valid EAPOL
Logoff frames that have
been received by the switch.
Rx Invalid Type dot1xAuthInvalidEapolF
ramesRx
The number of EAPOL
frames that have been
received by the switch in
which the frame type is not
recognized.
Rx Invalid Length dot1xAuthEapLengthErr
orFramesRx
The number of EAPOL
frames that have been
