User’s Manual of WGSW-20160HP/WGSW-24040HP series
The page includes the following fields:
Object Description
• System PoE Admin
Mode
Allows user enable or disable PoE function. It will causes all of PoE ports supply
or not supply power.
• PoE Temperature
Protection
Allows user enable or disable PoE Temperature Protection.
• PoE Management
Mode
There are five modes for configuring how the ports/PDs may reserve power and
when to shut down ports.
Classification mode: System reserves PoE power to PD according to PoE class
level.
Allocation mode: allows user to assign PoE power to per port.
Consumption mode: System offers PoE power accordint to PD real power
consumption.
Priority mode: System offers PoE power according to per port priority setting
when power consumption has been over total power budget.
The default PoE management mode is “Consumption mode”.
• Power Supply Budget
[W]
Set limit value of the total PoE port provided power to the PDs.
For WGSW-20160HP, the available maximum value is 230.
For WGSW-24040HP, the available maximum value is 220.
For WGSW-24040HP4. the available maximum value is 440.
• Temperature
Threshold
Allows setting over temperature protection threshold value. It system
temperature was over it then system lower total PoE power budget automatically.
• PoE Usage Threshold
Allows setting how much PoE power budget could be limited.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
For WGSW-20160HP, the total PoE power reservation from port1 to port16 is up to 230
watts.
For WGSW-24040HP, the total PoE power reservation from port1 to port24 is up to 220
watts.
For WGSW-24040HP4, the PoE power reservation from port1 to port12 is up to 220 watts,
and from port13 to port24 is up to 220 watts, Totally 440 watts.
