User’s Manual of WGSW-20160HP/WGSW-24040HP series
Object Description
• Profile
Set the schedule profile mode. Possible porifles are:
Profile1
Profile2
Profile3
Profile4
• Week Day
Allows user to set week day for defining PoE function should be enabled on the day.
• Start Hour
Allows user to set what hour does PoE function enables.
• Start Min
Allows user to set what minute does PoE function enables.
• End Hour
Allows user to set what hour does PoE function disables.
• End Min
Allows user to set what minute does PoE function disables.
• Reboot Enable
Allows user to enable or disable whole PoE port reboot by PoE reboot schedule.
Please be noticed that if you want to PoE schedule and PoE reboot schedule work
at the same time, please use this function, and don’t use Reboot Only function.
This function offers administrator to reboot PoE device at indicate time if
administrator has this kind of requirement.
• Reboot Only
Allows user to reboot PoE function by PoE reboot schedule. Please be noticed that if
administrator enable this function, PoE schedule will not to set time to profile. This
function just ony for PoE port reset on the indicate time.
• Reboot Hour
Allows user to set what hour PoE reboots. This function only for PoE reboot
schedule.
• Reboot Min
Allows user to set what minute PoE reboots. This function only for PoE reboot
schedule.
Buttons
: click to add new rule.
: Click to save changes.
: Check to delete the entry.
