User’s Manual of WGSW-20160HP/WGSW-24040HP series
71
Client Statistics
Object Description
• Transmit to Client
The packets number that relayed packets from server to client.
• Transmit Error
The packets number that erroneously sent packets to servers.
• Receive from Client
The packets number that received packets from server.
• Receive Agent Option
The packets number that received packets with relay agent information option.
• Replace Agent Option
The packets number that replaced received packets with relay agent information
option.
• Keep Agent Optin
The packets number that kept received packets with relay agent information
option.
• Drop Agent Option
The packets number that dropped received packets with relay agent information
option.
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Clear all statistics.
