Administrator’s Guide for the Polycom RealPresence Group Series System Back Panel Views
Polycom, Inc. 176
8 Audio/Video >
Audio > Audio
Input > Type: Line
Audio Input 3 RCA Auxiliary audio input
Intended as microphone input; sent
to far end only
9 Audio/Video >
Audio > Audio
Input > Type: Line
Out
Audio Output RCA Audio output for main monitor
audio
Audio Mix Routed to the Output:
System tones and sound effects +
Audio from the far site +
Audio input from audio inputs 1 and
2, and 3 when associated video is
selected
10 Audio/Video >
Monitors > Monitor
1
Audio/Video >
Monitors > Monitor
2
Video output 1/2 SDI Output for Monitor 1 (VisualBoard
disabled)
Output for Monitor 2 (VisualBoard
enabled)
The SDI output does not include
embedded audio
11 Audio/Video >
Monitors > Monitor
1
Audio/Video >
Monitors > Monitor
2
Video output 1/2 HDMI Output for Monitor 1 (VisualBoard
disabled)
Output for Monitor 2 (VisualBoard
enabled); does not include
embedded audio
12 Audio/Video >
Monitors > Monitor
1
Audio/Video >
Monitors > Monitor
2
Audio/Video >
Monitors > Monitor
3
Video output 1/2/3 HDMI Output for Monitor 1 (VisualBoard
enabled)
Output for Monitor 2 (VisualBoard
disabled); does not include
embedded audio
Output for Monitor 3; does not
include embedded audio
Reference
Number
Location in
Web Interface:
Admin Settings > Input/Output
Supported
Formats Description
