Administrator’s Guide for the Polycom RealPresence Group Series System Back Panel Views
Polycom, Inc. 179
Note: Use either the HDMI or VGA for video input 3, but not both.
9 Audio/Video >
Video Inputs >
Input 4
VIdeo Input 4 Composite
Video
Video input
Associated with audio input 4 (audio is
disabled until video input 4 is selected)
10 Audio/Video >
Video Inputs >
Input 4
Video Input 4 Component
Video
Video input associated with audio input 4
(audio is disabled until video input 4 is
selected)
11 Audio/Video >
Audio > Audio
Input > Type:
Component
Audio Input 4 RCA Associated with video input 4
Inactive until video input is selected
Audio is included in local audio mix when
video source is selected
Note: Use either the Composite/RCA or Component for input 4, but not both.
12 Audio/Video >
Audio > Audio
Input > Type: Line
Audio Input 2 RCA Auxiliary audio input
Intended as microphone input; sent to far end
only
13 N/A Audio Input 1 Polycom
Microphone
Audio input for up to three Polycom
microphone arrays or a SoundStation IP 7000
speaker phone or SoundStructure mixer
14 N/A Audio Output 2 RCA Audio output for main monitor audio
Audio Mix Routed to the Output:
System tones and sound effects +
Audio from the far site +
Audio input from audio inputs 3 and 4 when
associated video is selected
15 Audio/Video >
Monitors > Monitor
1
Video Output 1 VGA Output for Monitor 1
16 Audio/Video >
Monitors > Monitor
1
Video Output 1
Audio Output 1
HDMI Output for Monitor 1
Audio Mix Routed to the Output:
System tones and sound effects +
Audio from the far site +
Audio input from audio inputs 3 and 4 when
associated video is selected
17 Audio/Video >
Monitors > Monitor
2
Video Output 2 VGA Output for Monitor 2
18 Audio/Video >
Monitors > Monitor
2
Video Output 2 HDMI Output for Monitor 2
Ref.
Number
Location in
Web Interface:
Admin Settings > Input/ Output
Supported
Formats Description
