© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 184
13 Replace the wave washer and flat belt pulley onto the drive input pulley shaft and secure with the snap
ring. Make sure the snap ring is fully seated into the shaft groove.
14 Adjust the Input and Generator pulley tension. Go to "Inspecting and Adjusting the Generator Belt
Tension" procedure.
15 Lift the stairarms and then thread the flat belts over the flat belt pulleys.
16 Select the QUICKSTART program and adjust the resistance up ▲ key until resistance level 10 is
displayed. Pedal the AMT for approximately one minute and then recheck the belt tension.
FIGURE 170: GENERATOR
