© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 222
Caution: It is recommended to have assistance available for following step(s).
49 With the assistance, lift the front of the Incline platform until the Incline tube mounting holes align with
the Incline platform mounting holes.
50 Replace the Incline motor mounting pin through the Incline tube and Incline platform and attach the hitch
pin.
51 Secure the flat belt clamps the lift arm housing using the four 3/8-16 X 3 mounting bolts and washers.
52 Lift the stairarms and thread the flat belts through the pulleys.
53 Replace the covers as per procedure, Cover Replacement (on page 53).
Replacing a Tie Rod
Procedure
1 Remove the covers as described per procedure, Cover Replacement (on page 53).
2 Remove the tie rod mounting bolt and washer that secures the lower tie rod end to the cam assembly.
3 Remove the tie rod mounting bolt and washer that secures the upper tie rod end to the upper arm axle.
4 Fasten the replacement upper tie rod end to the upper arm axle using the bolt and washer removed in
step 3, torque the bolt to 300 inch pounds.
5 Fasten the replacement lower tie rod end to the cam assembly using the bolts and washer removed in
step 2, torque the bolt to 300 inch pounds.
6 Replace the covers as described per procedure, Cover Replacement (on page 53).
FIGURE 220: TIE RODS
