© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 221
Gas Shock Installation
46 Rotate the gas shock up.
47 Adjust the height of the gas shock by lowering or raising the front of the Incline platform until the gas
shock and the upper mounting stud align.
48 Press the gas shock onto the mounting stud and secure the gas shock to the upper mounting stud by
pushing in on the tension clip.
FIGURE 219: GAS SHOCK
