Inspecting and Adjusting the Generator Belt Tension
WARNING: Before continuing with this procedure, review the Warning and Caution statements listed
in the Warning and Caution Statements and General Safety Guidelines Section, Things You Should
Know.
Procedure
1 Remove the gasket, top, front, rear, left and right side covers per procedure, Cover Replacement (on
page 53).
2 Place a belt gauge on the generator belt as shown in below.
FIGURE 252: GENERATOR BELT
